Multiport Valves

Multiport valve blocks are often installed when complex solutions in process engineering systems are required. Compared with welded designs, these valves require minimal space and are optimised to prevent deadleg.

The compact design of the valve seats significantly reduces the size of the area that comes into contact with the media in a multiport valve block compared to a conventional welded or ring design. A smaller fluid chamber means less risk of contamination and can also considerably reduce product loss and plant size.

Our multiport valve blocks are entirely custom-made according to your specific requirements.

Product features

  • Compact, space-efficient design
  • Minimised deadleg
  • Without welds
  • Unique chambered sealing system
  • Optimised design for CIP/SIP operations
  • Operating pressure up to 20 bar
  • Customised material selection and design
  • Welding ends or clamps according to different standards (e.g. DIN, ISO, ASME)
  • Due to the modular design principle, individual customer requirements are flexibly implemented
  • DN 6 to DN 150
SISTO-CM552 with pneumatic actuators
SISTO-CM547 with manual actuators
SISTO-CM1200 with pneumatic actuators
SISTO-CM205 with pneumatic actuators
SISTO-CM441 with pneumatic actuators
SISTO-CM509 with pneumatic actuators
SISTO-CM492 with manual actuators
SISTO-CM4114 with pneumatic actuators
SISTO-CM492 with manual actuators

Project support

We manufacture our multiport valves on a customer-specific basis and accompany our customers from the initial enquiry to the implementation of their projects.

We provide support as early as the planning stage with ideas and initial design drafts. We then create 3D models in close consultation with our customers. The final design is manufactured in our own production facilities using state-of-the-art technology and in accordance with the high requirements of our customers.

Design Overview

The production of individual and customised multiport valves is one of our core areas of expertise.

Here you will find a small selection from the large variety of multiport valves already created by us.

Further designs are of course possible!

Number of diaphragm seats

  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 15

3D Data

Here you can find a selection of 3D models
view here

We will be happy to provide you with further data on request


All documents downloadable and catalogue as flipbook (button on the right)

Approvals & Certificates

  • Declaration of conformity DGRL 2014/68/EU

    PED 2014/68/EU

  • Certification

    CE certificate nach DGRL/PED (2014/68/EU)

  • Certification

    ISO 9001

  • Certification

    ISO 14001

  • Certification

    ISO 45001
